META POWER SX AVINOX, 160 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
Motor
AVINOX
120 Nm peak torque with a 1,000 W boost mode, and 105 Nm / 850 W in normal operation
Battery
AVINOX
600 W on S, 800 W on M / L / XL, Fully integrated main battery
AVINOX 508w Fast Battery charger
Display
AVINOX DP100 : Integrated and colored touchscreen providing a large range of information : speed, ride mode, battery range, charge level, fitness data, elevation gain, altitude and many more. It also features a USB-C port, GPS sensor, barometer, compass, 4G connection and even a theft alarm system.
AVINOX BD100, ON/OFF switch, assist mode level, battery charge level
Switch: AVINOX BC100, mode switch, walk assist, light switch
Shock
FOX Float X Factory
230 x 60 mm, 2-postion (open/firm) lever, HSC, LSC, HSR, LSR, 0.4ci Spacers
Fork
FOX 36 Factory 160 mm
29", Grip X2 damper, HSR, LSR, HSC, LSC, Boost (15 x 110 mm), 44 mm offset
Headset
ACROS ZS56 / ZS66
Alloy cups, stainless steel & sealed bearings
Stem
RIDE ALPHA 40
40 mm extension, 31.8 mm
Handlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI LONGNECK V2.1
Soft compound, single clamp, black
Brakes
SHIMANO XT, 4 pistons
Rotors: GALFER SHARK, 6-bolt, 203 mm
Shifters
SRAM AXS POD
12s
Chain guide
RIDE ALPHA
32-34t
REAR DERAILLEUR
SRAM GX EAGLE T-TYPE
12s
Crankset
E13 HELIX RACE, 155 mm crank arms, Bosch
Chainring: SRAM CR T-TYPE, 34t, BCD 104
Chain
SRAM GX EAGLE T-TYPE
12s, Flat Top
Cassette
SRAM X0 EAGLE T-TYPE
12s, 10-52t
Rims
DT SWISS HX1700
Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
Hubs
DT SWISS 350 Hybrid
Rear: 28h, sealed bearings, 12 x 148 mm, SRAM XD - Front: 28h, sealed bearings, 15 x 110 mm
Spokes/nipples
DT SWISS Hybrid 1
Straightpull, 2.34/2.0mm, double butted, stainless, with ProLock, black
Tyres
Rear: MAXXIS MINION DHRII 27.5'' - Front: MAXXIS MINION DHRII 29'
Rear: 27.5x2.50WT 3C MaxxTerra / EXO+ Casing / TR- Front: 29x2.50WT 3C MaxxTerra / EXO+ Casing / TR
Seat post
ONE UP V3
31.6 mm, 150 mm on S, 180 mm on M and 210 mm on L/XL
Saddle
WTB SOLANO
142 x 240 mm, Medium
Weight
- kg / - lbs
Minimum weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
CRANKBROTHERS Stamp
Colour
Pure Black
Shiny Finish
Accessories
Full RIDEWRAP protective film, motor protector, chain stay protector, seat stay protector, FIDLOCK base, fork fender,CRANKBROTHERS STAMP 1 pedals
